Total TAC2182301HT Ultrathin diamond disc（Mesh rim） 230mm

Total TAC2182301HT is a 230mm (9″) heavy-duty, ultra-thin mesh-rim diamond cutting disc equipped with an integrated center reinforcement flange plate. Designed for large 9″ angle grinders and masonry cut-off saws, the patterned mesh rim delivers fast heat dissipation, efficient dust ejection, and clean, chip-free cuts across large stone and tile surfaces.

Key Specifications

• Outer Diameter: 230 mm (9 inches)

• Bore / Shaft Diameter: 22.2 mm (7/8 inches)

• Blade Thickness: 1.8 mm ultra-thin kerf

• Matrix Core Thickness: 1.2 mm high-grade 75Cr1 alloy steel

• Diamond Segment Height: 10 mm mesh rim

• Reinforcement: Integrated center flange plate to prevent blade flex and wobble

• Cutting Type: Suitable for both dry and wet cutting

• Tool Compatibility: Standard 9″ (230mm) large angle grinders and stone/tile cutting power tools
