Total TAT10601 Air spray gun 600cc
KSh3,650.00
Key Features & Capabilities
-
Gravity Feed Advantage: The top-mounted 600cc plastic cup utilizes gravity to channel paint directly into the fluid tip, ensuring maximum paint utilization down to the last drop with minimal residue.
-
Fine-Finish 1.4 mm Nozzle: Perfectly sized for smooth, atomized topcoats, varnishes, basecoats, and clear coats without excessive orange-peel texture.
-
3 Control Knobs:
-
Fluid Control: Adjusts the amount of paint released per trigger pull.
-
Pattern Control: Switches between a wide fan pattern ($180\text{–}250\text{ mm}$) for broad surfaces and a narrow round pattern for small rails.
-
Air Adjustment: Regulates incoming air pressure at the base of the handle.
-
-
Universal Fitting Kit: Ships with multiple standard quick-connect air fittings (Europe, USA, Nitto, and Italy types) to connect directly to standard air compressor hoses.
TOTAL TAT10601 is a gravity-feed pneumatic air spray gun equipped with a 600cc top-mounted paint cup. Designed for connection to an external air compressor, it features a 1.4 mm standard nozzle ideal for fine finishing coats, automotive touch-ups, furniture lacquering, and clear coat applications.
Technical Specifications
| Parameter | Specification |
| Model Number | TAT10601 |
| Feed Type | Gravity Feed (Top Cup) |
| Paint Cup Capacity | 600 cc |
| Standard Nozzle Size | 1.4 mm |
| Optional Nozzle Sizes | 1.3 mm – 2.5 mm |
| Operating Air Pressure | 2.0 – 3.5 bar (29 – 50.8 PSI) |
| Max Air Pressure | 8.3 bar (120 PSI) |
| Air Consumption | 119 – 200 L/min (4.2 – 7.1 CFM) |
| Pattern Width | 180 – 250 mm |
| Air Inlet Thread | 1/4″ |
| Weight | ~0.75 kg |
| Weight | 5 lbs |
|---|
