Total TWP515006 4″ Deep well pump 1500W(2.0HP) Max.head:135m
KSh37,999.00
4″ Deep well pump
Voltage:220-240V~50Hz
Rated power:1500W(2.0HP)
Max.head:135m
Max.flow:6.7m³/h
Pipe diameter:1-1/4″
Well pump body:4″
Impeller:18 stage
Copper wire motor
Outlet :Brass
Inlet: Brass
Oil chamber: Brass
Pump body:Stainless steel
20m length cable
1pcs control box
Packed by carton box
Description
Technical Specifications
| Feature / Specification | Detail |
| Model | TWP515006 |
| Rated Power | 1500W / 2.0 HP |
| Voltage / Frequency | 220–240V ~ 50Hz |
| Maximum Head (Pumping Height) | 135 meters |
| Maximum Flow Rate | 6.0 m³/h (~100 L/min) |
| Pump Casing Diameter | 4″ (Fits standard 4-inch borehole casing) |
| Outlet/Pipe Diameter | 1-1/4″ (1.25 inches) |
| Impeller Configuration | 18-stage plastic/plastic-alloy impellers |
| Motor Winding | 100% Copper Wire Motor |
| Cable Length | 20 meters included |
| Included Accessories | External Control Box (1 pc) |
Additional information
| Weight | 5 lbs |
|---|
