Total TWP57506 4″ Deep well pump 750W(1.0HP) 80M
KSh25,500.00
4″ Deep well pump
Voltage:220-240V~50Hz
Rated power:750W(1.0HP)
Max.head:80m
Max.flow:6.7m³/h
Pipe diameter:1-1/4″
Well pump body:4″
Impeller:10 stage
Copper wire motor
Outlet :Brass
Description
TOTAL TWP57506 4″ Submersible Deep Well Pump is a commercial-grade borehole pump engineered for high-lift water delivery. Delivering up to 80 meters of maximum head with a 1.0 HP motor, it provides robust water pressure for deep wells, high-elevation tanks, and agricultural irrigation.
Technical Specifications
| Specification | Details |
| Model | TWP57506 |
| Input Power | 750W (1.0 HP) |
| Voltage / Frequency | 220V–240V ~ 50Hz |
| Maximum Head | 80 meters |
| Maximum Flow Rate | 6.7 m³/h (111.6 L/min) |
| Pump Outer Diameter | 4″ (Fits standard 4-inch or larger well casings) |
| Pipe Outlet Diameter | 1.25″ (G1-1/4) threaded discharge |
| Impeller System | 10-stage multi-stage plastic impellers |
| Motor & Chamber Construction | 100% Copper wire motor; heavy-duty brass inlet, outlet, and oil chamber |
| Body Material | Stainless steel pump casing |
| Included Accessories | External control box & 20m power cable |
Additional information
| Weight | 5 lbs |
|---|
