Total TSCM120 Water pump 120W 8M
KSh9,999.00
Key Features & Applications
-
High Temperature Capacity (Up to 110°C): Engineered with heat-resistant seals and a durable PPO/brass impeller capable of handling high-temperature fluid loops without degradation.
-
3-Speed Control Switch: Features a 3-position selector switch allowing you to adjust power output, flow rate, and pressure depending on system demand (helping lower energy draw when full output is not required).
-
Quiet Inline Operation: Operates with near-silent running acoustics, making it suitable for indoor residential installations behind walls, near boilers, or under sinks.
-
100% Copper Motor Winding: Reduces thermal build-up during long continuous duty cycles in heating loops.
TOTAL TSCM120 is a compact 120W inline hot water circulating pump. Unlike standard suction surface pumps, it is specifically designed for continuous water circulation in closed-loop heating systems, solar hot water installations, underfloor heating, and domestic hot water boost lines.
Technical Specifications
| Parameter | Specification |
| Model Number | TSCM120 |
| Pump Type | Hot Water Circulating Pump |
| Rated Power Input | 120 W |
| Voltage / Frequency | 220–240V ~ 50Hz (Single Phase) |
| Max Lift Head | 8 meters |
| Max Flow Rate | 23 L/min (1,380 L/hr) |
| Max Fluid Temperature | 110 °C (Handles boiling water/steam) |
| Inlet / Outlet Size | 20 mm × 20 mm (3/4″ threaded) |
| Speed Settings | 3-Position manual speed selector switch |
| Motor Winding | 100% Copper Wire Motor |
| Impeller Material | PPO Composite + Brass |
| Weight | 5 lbs |
|---|
