Total TMT5110004 Digital multimeter 1000V 9999 counts

TOTAL TMT5110004 is a top-tier 9999-count True RMS smart digital multimeter featuring a high-resolution VA color display, dual-mode operation (Smart Auto + Manual), and temperature measurement capability.

Key Measurement Ranges

• DC Voltage: 99.99mV / 999.9mV / 9.999V / 99.99V / 999.9V (Up to 1000V DC)

• AC Voltage: 99.99mV / 999.9mV / 9.999V / 99.99V / 750V (True RMS)

• AC/DC Current: 9.999mA / 99.99mA / 999.9mA / 9.999A

• Resistance: 999.9Ω / 9.999kΩ / 99.99kΩ / 999.9kΩ / 9.999MΩ / 99.99MΩ

• Capacitance: 9.999nF / 99.99nF / 999.9nF / 9.999µF / 99.99µF / 999.9µF / 9.999mF / 99.99mF

• Frequency: 9.999Hz to 9.999MHz

• Temperature Range: -40°C to 1000°C (-40°F to 1832°F)

• Duty Cycle: 1% to 99%

Key Features & Functions

• Display: Ultra-clear 9999-count VA color screen providing sharp legibility in high-glare or pitch-black settings

• Smart Auto & Manual Control: Auto-detects voltage, resistance, or continuity automatically, while retaining full manual overrides for precise range selection

• True RMS Measurement: Delivers accurate AC voltage/current readings on non-linear sine waves (e.g., VFDs, switching power supplies)

• Safety & Detection: Non-Contact Voltage (NCV) sensor, Live line identification, dual ceramic fuse protection, and blown-fuse indication

• Workplace Utility: Integrated LED work light, Data Hold, Relative (REL) mode, Min/Max tracking, and Auto Power-Off

• Safety Rating: CAT III 1000V / CAT IV 600V

• Power Supply: 3 × AAA (LR03) batteries
